Especificações
Disponibilidade16 unid.
MarcaINA
Número do artigoSL182205-A-XL-C3 INA
Manufacturer Part Number0501687460030
Também conhecido como
NCF2205V/C3
SL182205-A-C3
EAN4012802708431
CategoriaRolamento de rolos cilíndricos
Peso e dimensões
Interno (d) mm
25
Externo (D) mm
52
Largura (B) mm
18
Interno (d) polegadas
0.9843
Externo (D) polegadas
2.0472
Largura (B) polegadas
0.7087
Peso (kg)
0.18
Características do produto
Furo
C - furo cilíndrico
Vedação
Sem vedação
Tipo de gaiola
FC - sem gaiola (full comnplement)
Modificação externa
Sem modificação externa
Folga radial interna
Folga radial interna C3 (maior que Cn)
Precisão
Precisão standard
Estabilização térmica
Sem estabilização térmica - temperaturaa até 120 °C
Dados da Schaeffler (medias)
Largura (b) mm
18
Fator de carga radial estática C0r (N)
44500
Fator de carga radial dinâmica Cr (N)
51000
Fator de carga estática básica, radial (C 0r)
"44500.0000"
Velocidade limite (n G)
10300
Velocidade de referência (n ϑr)
5500
Número ECLASS
23-05-09-01
Número ECLASS2
23-05-09-01
Descrição do Medias
Cylindrical roller bearing SL1822..-A-XL, full complement roller set, single row, semi-locating bearing, 1 rib on outer ring, 2 ribs on inner ring, type SL18
Descrição do sufixo
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
The SL182205-A-XL-C3 INA is a single-row, full-complement cylinder bearing. This bearing type has a solid outer and inner ring and a high number of cylindrical rollers. These rollers are guided between the ribs of the rings. Since there is no cage, the maximum number of rolls can be used. As a result, these bearings can support very high radial loads. However, the maximum speed is lower than the speed of cylindrical roller bearings with cages. Single-row full-complement cylindrical roller bearings can also support axial forces in one direction. They are used as support bearings. Support bearings allow axial displacement of the shaft relative to the housing in one direction. The shaft is located axially in the other direction.
The SL182205-A-XL-C3 INA is an X-life type cylindrical roller bearing. X-life bearings provide better performance than normal cylindrical roller bearings due to a special internal construction. Contact surfaces, steel grade and rolling bodies are of a higher quality. X-life bearings combine a higher load capacity with a longer service life. The bearings generate less heat and allow for higher speeds. Finally, X-life bearings allow for longer maintenance intervals compared to normal cylindrical roller bearings.
