Folga axial interna / pré-carga
UL - execução universal para montagem aos pares, o par de rolamentos tem uma leve pré-carga nas disposições em O ou em X
Lubrificação
DLR
Dados da Schaeffler (medias)
Largura (b) mm
24
Fator de carga radial estática C0r (N)
26000
Fator de carga radial dinâmica Cr (N)
34500
Fator de carga estática básica, radial (C 0r)
"26000.0000"
Velocidade limite para lubrificação com graxa (n G Graxa)
15000
Velocidade limite para lubrificação a óleo (n G Óleo)
22000
Número ECLASS
23-05-08-03
Número ECLASS2
23-05-08-03
Descrição do sufixo
E25° Contact Angle
DLRDirect Lube, Integral O-Ring
TTextile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4SBoundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
The HC7020-EDLR-T-P4S-UL FAG is a high-speed design hybrid spindle bearing. This bearing type without seals has small ceramic balls. Hybrid spindle bearings can reach very high speeds with very little heat generation and wear. Even at very high speeds, a high degree of rigidity is maintained. This makes the HC7020-EDLR-T-P4S-UL FAG particularly suitable for use in high-speed- or grinding spindles.
FAG spindle bearings are single-row, angular contact ball bearings that cannot be dismantled. They have solid inner and outer rings as well as ball-and-cage assemblies with solid window cages. Due to their extremely tight tolerances, they are particularly suitable for applications that require high guidance accuracy and suitability for high speeds. Spindle bearings are commonly used for main spindles in machine tools.
In addition, FAG spindle bearings are designed as universal bearings. Universal bearings with the same deviation in inner ring bore and outer diameter can be combined for use in different arrangements. For example, when the load capacity of a single bearing is insufficient, two matching bearings can be used in a tandem arrangement to support axial loads in one direction only. In order to support axial loads in both directions as well as moments, O or X arrangements are good solutions.
