Vedação
2RS - vedação de borracha em ambos os lados
Material de contato
Aço sobre PTFE
Dados da Schaeffler (medias)
Diâmetro externo do rolamento (D) mm
42
Fator de carga radial estática C0r (N)
65500
Largura do anel interno (B) mm
20
Fator de carga radial dinâmica Cr (N)
128000
Fator de carga estática básica, radial (C 0r)
"65500.0000"
Número ECLASS
23-05-01-05
Número ECLASS2
23-05-01-05
Descrição do Medias
Hydraulic rod end, with thread clamping device, right hand thread, maintenance-free, sliding layer: ELGOGLIDE, sealed design
Descrição do sufixo
UKSliding Contact Surface Hard Chromium/PTFE Composite
2RSLip Seals On Both Sides
CThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
The GIHRK25-UK-2RS-C INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.
The GIHRK25-UK-2RS-C INA has a spherical plain bearing with a steel-on-PTFE sliding contact, making it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.
