Name: GE50-AW-A INA
Brand: INA

Especificações

Disponibilidade 4 unid.
Marca INA
Número do artigo GE50-AW-A INA
Manufacturer Part Number 0066517550000
EAN 4012802532609
Categoria Rótulas

Peso e dimensões

Interno (d) mm 50
Externo (D) mm 130
Largura (B) mm 42,5
Interno (d) polegadas 1.9685
Externo (D) polegadas 5.1181
Largura (B) polegadas 1.6732
Peso (kg) 3.2

Características do produto

Vedação Sem vedação
Material de contato Aço sobre PTFE

Dados da Schaeffler (medias)

Diâmetro externo do rolamento (D) mm 130
Altura (T) mm 42,5
Largura do anel interno (B) mm 33,5
Fator de carga axial estática C0a (N) 3250000
Fator de carga axial dinâmica Ca (N) 1950000
Número ECLASS 23-05-01-06
Número ECLASS2 23-05-01-06
Descrição do Medias Axial spherical plain bearing, maintenance-free, DIN ISO 12240-3, shaft location washer curved surface with hard chromium coating, open design

Descrição do sufixo

AW Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Transferências e Links

Link to manufacturer

Descrição do produto

The GE50-AW-A INA is an axial spherical plain bearing. Axial spherical plain bearings are two-piece plain bearings. They have no rolling elements, but consist of a shaft washer and a housing washer. The shaft washer has a convex surface. The housing washer has a concave inner surface. This construction gives spherical plain bearings their high load carrying capacity and capacity to accommodate misalignment.

The GE50-AW-A INA has a steel-on-PTFE sliding contact which makes it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.

GE50-AW-A INA

Axial spherical plain bearing
