Name: GE35-UK-2RS-A INA
Brand: INA

Especificações

Disponibilidade 60 unid.
Marca INA
Número do artigo GE35-UK-2RS-A INA
Manufacturer Part Number 0066502280000
Também conhecido como GE35TXE-2RS
EAN 4012802531930
Categoria Rótulas

Peso e dimensões

Interno (d) mm 35
Externo (D) mm 55
Largura (B) mm 25
Interno (d) polegadas 1.378
Externo (D) polegadas 2.1654
Largura (B) polegadas 0.9843
Peso (kg) 0.22

Características do produto

Vedação 2RS - vedação de borracha em ambos os lados
Material de contato Aço sobre PTFE

Dados da Schaeffler (medias)

Diâmetro externo do rolamento (D) mm 55
Fator de carga radial estática C0r (N) 353000
Largura do anel interno (B) mm 25
Fator de carga radial dinâmica Cr (N) 212000
Fator de carga estática básica, radial (C 0r) "353000.0000"
Número ECLASS 23-05-01-06
Número ECLASS2 23-05-01-06
Descrição do Medias Radial spherical plain bearing, maintenance-free, sliding layer: ELGOGLIDE, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series E, sealed

Descrição do sufixo

UK Sliding Contact Surface Hard Chromium/PTFE Composite
2RS Lip Seals On Both Sides
A Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard)

Transferências e Links

Link to manufacturer

Descrição do produto

The GE35-UK-2RS-A INA is a spherical plain bearing. Spherical plain bearings are two-piece plain bearings. They have no rolling elements, but consist of an inner and outer ring. The inner ring has a convex outer surface. The outer ring has a concave inner surface. This construction gives spherical plain bearings their high load carrying capacity and capacity to accommodate misalignment.

The GE35-UK-2RS-A INA has a steel-on-PTFE sliding contact which makes it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.

GE35-UK-2RS-A INA

Spherical plain bearing
