Home › 3-Phase Motors › TS56B2B5 DR Drives

TS56B2B5 DR Drives

56-2P 0,12kW 230/400V B5 AL

TS56B2B5-DR-Drives/900111

not in stock

Quotes sent within 1 hour
Quotes include shipping costs

Loading equivalents

Specifications

Availability 0 pcs
Brand DR Drives
Item Number TS56B2B5 DR Drives
Category 3-Phase Motors

Weight and Dimensions

Weight (kg) 3.2

Product Properties

Rated power (kW) 0.12
Speed at 50Hz (rpm) 3000 / 2-Poles
Frequency 50/60 Hz
Energy efficiency Not applicable
Mounting B5 (outer flange)
Brake No Brake
IP Class IP55
Explosion safety (Atex) No protection
IEC Framesize 56

Detailed Product Properties

Voltage 220-230VD / 380-400VY
Shaft diameter (inch) 0.625
Housing material Alu
AC/DC AC
NEMA framesize 56
Standard IEC
Shaft height NEMA in JDE 056
Shaft length (inch) 1.875
Shaft height, B3 mounted (inch) 3.5
Width foot holes, B3 mounted (inch) 4.875
Length foot holes, B3 mounted (inch) 3
Diameter foot holes (inch) 0.3438
Pitch flange holes C-face (inch) 5.875
Outer diameter flange C-face (inch) 6.5
Spigot C-face (inch) 4.5
