1LE1003-0DB22-2KA4 Siemens

80-4P 0,55kW 230/400V B14 AL

1LE1003-0DB22-2KA4 Siemens
1LE1003-0DB22-2KA4 Siemens
1LE1003-0DB22-2KA4 Siemens
1LE1003-0DB22-2KA4 Siemens
1LE1003-0DB22-2KA4 Siemens
1LE1003-0DB22-2KA4 Siemens
1LE1003-0DB22-2KA4 Siemens
1LE1003-0DB22-2KA4 Siemens

8 pcs in stock

  • This product is available from stock
  • Shipment until 18:00 CET on business days
  • Payment by invoice possible
  • Track your order with track & trace
Loading equivalents

Specifications

Weight and Dimensions

Product Properties

Detailed Product Properties

Downloads & Links

Product description

SIMOTICS GP MOTOR TYPE: 1AV3082B LOW-VOLTAGE MOTOR, IEC SQUIRREL-CAGE,SELF-VENTIL.,IP55 TEMP. CL. 155(F) ACC.TO 130(B) ALUMINIUM HOUSING PREMIUM EFFICIENCY, 4POLE * FS80M * 0.55KW (50HZ) 0.63KW (60HZ) 3 AC 50HZ 230VD/400VY * 3 AC 60HZ 460VY IM B 14, STANDARD FLANGE: FT100(C120) without motor protection TERMINAL BOX AT TOP

Product
Article Number (Market Facing Number) 1LE1003-0DB22-2KA4
Product Description SIMOTICS GP MOTOR TYPE: 1AV3082B LOW-VOLTAGE MOTOR, IEC SQUIRREL-CAGE,SELF-VENTIL.,IP55 TEMP. CL. 155(F) ACC.TO 130(B) ALUMINIUM HOUSING PREMIUM EFFICIENCY, 4POLE * FS80M * 0.55KW (50HZ) 0.63KW (60HZ) 3 AC 50HZ 230VD/400VY * 3 AC 60HZ 460VY IM B 14, STANDARD FLANGE: FT100(C120) without motor protection TERMINAL BOX AT TOP
Product family Aluminum series 1LE1003 - Self-ventilated
Product Lifecycle (PLM) PM300:Active Product
Price data
Price Group / Headquarter Price Group 08B / 3Z1
List Price EUR
Customer Price EUR
Metal Factor N-W-----
Delivery information
Export Control Regulations AL : N / ECCN : N
Standard lead time ex-works 10 Day/Days
Net Weight (kg) 11,000 Kg
Product Dimensions (W x L x H) Not available
Packaging Dimension Not available
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN Not available
UPC Not available
Commodity Code 85015100
LKZ_FDB/ CatalogID D81.1-1/IEC
Product Group 5114
Country of origin Germany
Compliance with the substance restrictions according to RoHS directive sinds: 01.12.2006
Product class C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit.
Categorie voor terugname electronische materialen na gebruik Geen terugname verplichting
Classifications

  Version Classification
eClass 5.1 27-02-21-01
eClass 6 27-02-21-01
eClass 7.1 27-02-21-01
eClass 8 27-02-21-01
eClass 9 27-02-21-01
eClass 9.1 27-02-21-01
