Lubrication Enhancement
W - No Lubrication Groove or Holes
Seal
2RS2 - Fluoro Rubber Seals / High Temperature
Cage Type
S - Steel or Standard Cage
Radial Internal Play
C4 Internal Play (Higher than C3)
Precision
Standard Precision
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution
Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm
38
Basic static load rating, radial (C 0r)
210000
Limiting speed (n G)
1740
Suffix description
E1Increased Capacity Design
XLX-Life
2VSRSheet Steel Reinforced Rubbing Seals Of Fluoro Rubber (FPM) At Both Sides Of The Bearing. Grease Fill 70 To 100% With A Plyurea High Temperature Grease. Annular Groove And Three Lubricating Holes In The Outer Ring
H40Bearings Without Lubricating Groove And Holes; H40 Replaces Z26, Completely Closed Outer Ring
The WS22213-E1-XL-2VSR-H40-C4 FAG is a spherical roller bearing. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.
The WS22213-E1-XL-2VSR-H40-C4 FAG is an X-life type bearing. X-life bearings provide better performance than normal spherical roller bearings due to a special internal construction. Contact surfaces, steel grade and rolling bodies are of a higher quality. X-life bearings combine a higher load capacity with a longer service life. The bearings generate less heat and allow for higher speeds. Finally, X-life bearings allow for longer maintenance intervals compared to normal spherical roller bearings.
