Specifications

• Availability 1 pc
• Brand INA
• Item Number RWU35-E-L-RROC-V3-G2 INA
• Also known as RWU35-E-L-RROC-G2-V3

• Category Linear Plain Bearing Unit

Weight and Dimensions

• Inner (d) MM 34
• Outer (D) MM 100
• Width (B) MM 41,5
• Inner (d) Inch 1.3386
• Outer (D) Inch 3.937
• Width (B) Inch 1.6339
• Weight (kg) 2.29

Product Properties

• Seal No Seal

Data from Schaeffler (medias)

• ECLASS number 23-30-04-90
• ECLASS2 number 23-30-04-90
• Medias description Long carriage with full complement recirculating roller system for linear recirculating roller bearing and guideway assembly, for oil or grease lubrication
