Home › Four Point Contact Ball Bearing › QJ228-N2-MPA-C3 FAG

QJ228-N2-MPA-C3 FAG

Four point contact bearings QJ2..-N2, main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots

QJ228-N2-MPA-C3 FAG

QJ228-N2-MPA-C3 FAG

QJ228-N2-MPA-C3 FAG

QJ228-N2-MPA-C3 FAG

QJ228-N2-MPA-C3 FAG

QJ228-N2-MPA-C3 FAG

QJ228-N2-MPA-C3 FAG

QJ228-N2-MPA-C3 FAG

3 pcs in stock

This product is available from stock
Orders placed before 6 p.m. CET will be shipped today
Payment by invoice possible
Track your order with track & trace
Official Schaeffler distributor

Loading equivalents

Specifications

Availability 3 pcs
Brand FAG
Item Number QJ228-N2-MPA-C3 FAG
Manufacturer Part Number 0190052450030
EAN 4012801267816
Category Four Point Contact Ball Bearing

Weight and Dimensions

Width (B) MM 42
Width (B) Inch 1.6535
Weight (kg) 9.7

Product Properties

Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring

Data from Schaeffler (medias)

Medias description Four-point contact bearing QJ2..-N2-MPA, inner ring split

Suffix description

N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
C3 Internal Clearance Larger Than Normal
