Specifications

• Availability 4 pcs
• Brand FAG
• Item Number QJ219-N2-MPA FAG
• Manufacturer Part Number 0192610980000
• Also known as QJ219N2MA

• EAN 4012801267663
• Category Four Point Contact Ball Bearing

Weight and Dimensions

• Inner (d) MM 95
• Outer (D) MM 170
• Width (B) MM 32
• Inner (d) Inch 3.7402
• Outer (D) Inch 6.6929
• Width (B) Inch 1.2598
• Weight (kg) 3.3

Product Properties

• Seal No Seal
• Cage Type MA - Brass Cage, Centered on Outer Ring
• External Modification N2 - 2 Locking Groove in Outer Ring
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Split Inner ring / Outer ring Split inner ring

Data from Schaeffler (medias)

• Width (b) mm 32
• Radial Static Load Rating C0r (N) 212000
• Radial Dynamic Load Rating Cr (N) 190000
• Basic static load rating, radial (C 0r) "212000.0000"
• Limiting speed (n G) 7000
• Reference speed (n ϑr) 3700
• ECLASS number 23-05-08-03
• ECLASS2 number 23-05-08-03
• Medias description Four-point contact bearing QJ2..-N2-MPA, inner ring split
