Specifications
Availability13 pcs
BrandINA
Item NumberPWTR50110-2RS-RR-XL INA
Manufacturer Part Number0645345610000
Also known as
PWTR50110-2RS-RR
EAN4054366811127
CategorySupport Roller
Weight and Dimensions
Inner (d) MM
50
Outer (D) MM
110
Width (B) MM
30
Inner (d) Inch
1.9685
Outer (D) Inch
4.3307
Width (B) Inch
1.1811
Weight (kg)
1.69
Product Properties
Seal
2RS - Rubber Seal on Two Sides
Running Surface
Standard
Data from Schaeffler (medias)
Width inner ring (B) mm
32
Basic dynamic load rating, radial (C r w)
60000
Basic static load rating, radial (C 0r)
92000
Speed on permanent grease lubrication (n D G)
1100
ECLASS number
23-05-15-01
ECLASS2 number
23-05-15-01
Medias description
Yoke type track rollers PWTR..-2RS-RR, Full complement cylindrical roller set, with axial guidance, lip seal on both sides, with Corrotect coating
Suffix description
2RSRubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120℃
RRProtected Against Corrosion By Corrotect® Special Coating
The PWTR50110-2RS-RR-XL INA is a track roller or support roller with cylindrical rollers. These rolling elements combine a high load capacity with reasonable shock resistance. Track rollers are designed for use with various types of tracks. Thanks to a thick-walled outer ring, they can withstand high radial loads. Axial loads due to alignment errors or misalignment can be absorbed in both directions. Yoke type track rollers are suitable for mounting on a shaft. They are not mounted in a housing bore, but a flat (counter) track provides support.
The PWTR50110-2RS-RR-XL INA has a full complement design. The absence of a cage allows for a greater number of rolling elements, making this track roller radially highly loadable. Full complement track rollers are also more shock-resistant than track rollers with a cage. However, the maximum rotational speed is lower than that of caged variants. Common applications of track rollers include conveyor systems, linear guidance systems, and cam mechanisms.
