Loading equivalents
Specifications
Availability6 pcs
BrandSKF
Item NumberPCM10010580M SKF
Also known as
EGB10080-E50
GLY.PG10010580A
PAP10080P20
PM10080DX
EAN7316571373386
CategoryBushing
Weight and Dimensions
Inner (d) MM
100
Outer (D) MM
105
Width (B) MM
80
Inner (d) Inch
3.937
Outer (D) Inch
4.1339
Width (B) Inch
3.1496
Weight (kg)
0.45
Suffix description
MSteel Backing With Sintered Tin Bronze Layer; Pore Filling And Covering Layer Of Acetal Resin (~0,3mm)
Product description
The PCM10010580M SKF is a bushing. Bushings have a very simple, one-piece cylindrical design without rolling elements. Instead, they have a sliding contact where the shaft slides into the bore. This construction makes these bushings a cost-effective and reliable solution. Additionally, they are easy to install and require little installation space. The direct contact between the bushing and the shaft results in greater friction between the surfaces. Compared to roller bearings, they have lower speed and load capacities. Bushings are primarily used for rotating, oscillating, and linear movements.
