Specifications
Availability1 pc
BrandFAG
Item NumberNN3017-AS-M-SP-C2 FAG
CategoryCylindrical Roller Bearing Double Row
Weight and Dimensions
Inner (d) MM
85
Outer (D) MM
130
Width (B) MM
34
Inner (d) Inch
3.3465
Outer (D) Inch
5.1181
Width (B) Inch
1.3386
Weight (kg)
1.55
Product Properties
Bore
C - Cylindrical Bore
Seal
No Seal
Cage Type
M - Brass Cage
External Modification
No External Modification
Radial Internal Play
C2 Internal Play (Less than Cn)
Precision
SP - Precision Higher than P4S
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Suffix description
ACylindrical Roller Bearings, Parts Interchangeable
SLubrication Groove And Three Holes In Bearing Outer Ring
MSolid Brass Cage, Roller Guided
SPSuper Precision Specification, Tolerance Class SP, Radial Clearance C1
C2Bearing Internal Clearance Smaller Than Normal
Product description
The NN3017-AS-M-SP-C2 FAG is a double-row precision cylindrical roller bearing. This bearing has a particularly high radial load capacity and high running accuracy. The design consists of a solid inner and outer ring with a double row of cylindrical rollers with a cage. The rolling elements are guided between flanges. This construction enables compact bearing arrangements with high radial stiffness and very high precision and load capacity. The outer ring is separable from the inner ring, facilitating (dis)assembly. Precision cylindrical roller bearings are often used, for example, in the main spindles of machine tools.
The NN3017-AS-M-SP-C2 FAG is equipped with a cage that prevents the cylindrical rollers from coming into contact with each other. This design allows for controlled movement of the rolling elements. There is less friction than in full-complement cylindrical roller bearings. As a result, higher rotational speeds are possible, and less heat is generated.
