Home › Needle Roller and Cage Assembly › NA4926-XL INA

NA4926-XL INA

Needle roller bearings NA49, dimension series 49, to DIN 617/ISO 1206

50 pcs in stock

This product is available from stock
Orders placed before 6 p.m. CET will be shipped today
Payment by invoice possible
Track your order with track & trace
Official Schaeffler distributor

Loading equivalents

Specifications

Availability 50 pcs
Brand INA
Item Number NA4926-XL INA
Manufacturer Part Number 0506616800000
Also known as NA4926
EAN 4047643205412
Category Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM 130
Outer (D) MM 180
Width (B) MM 50
Inner (d) Inch 5.1181
Outer (D) Inch 7.0866
Width (B) Inch 1.9685
Weight (kg) 3.9

Product Properties

Seal No Seal

Data from Schaeffler (medias)

Width (b) mm 50
Radial Static Load Rating C0r (N) 470000
Radial Dynamic Load Rating Cr (N) 229000
Basic static load rating, radial (C 0r) "470000.0000"
Limiting speed (n G) 3100
Limiting speed for grease lubrication (n G Grease) 1850
Reference speed (n ϑr) 2000
ECLASS number 23-05-09-07
ECLASS2 number 23-05-09-07
Medias description Radial roller bearing NA..-XL

Suffix description

XL X-Life
