Loading equivalents
Specifications
Availability21 pcs
BrandINA
Item NumberKR62-PP-A INA
Manufacturer Part Number0055830800000
EAN4012802418507
CategoryCam Follower
Weight and Dimensions
Inner (d) MM
24
Outer (D) MM
62
Width (B) MM
29
Inner (d) Inch
0.9449
Outer (D) Inch
2.4409
Width (B) Inch
1.1417
Weight (kg)
0.79
Product Properties
Seal
2L - LS-seal at Both Sides
Excenterring
Other Mounting Method
Running Surface
Standard
Data from Schaeffler (medias)
Fit diameter of roller stud / stud (d 1) mm
24
Width of the roller stud (B) mm
80
Basic dynamic load rating, radial (C r w)
26000
Basic static load rating, radial (C 0r)
48500
Speed on permanent grease lubrication (n D G)
1900
ECLASS number
23-05-15-02
ECLASS2 number
23-05-15-02
Medias description
Stud type track rollers KR..-PP, with axial guidance, plastic axial plain washers on both sides
Suffix description
PPLip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100℃
AAlteration In Internal Construction. Identical To Old Notation
The KR62-PP-A INA is a cam follower with needle rollers. These rolling elements combine high load capacity with a compact design. Cam followers are designed for use with various types of tracks. Thanks to a thick-walled outer ring, they can withstand high radial loads. Instead of an inner ring, they feature a solid, threaded stud, enabling easy mounting. Axial loads due to alignment errors or misalignment can be absorbed in both directions. They are not mounted in a housing bore, but a flat (counter) track provides support.
The KR62-PP-A INA is equipped with a cage that prevents the rolling elements from coming into contact with each other. This design allows for a controlled movement of the rolling elements. There is lower friction compared to full complement cam followers, allowing for higher rotational speeds and less heat generation. Common applications of cam followers include conveyor systems, linear guidance systems, and cam mechanisms.
