Loading equivalents
Specifications
Availability2 pcs
BrandSKF
Item NumberKR26PPA SKF
EAN7316571594293
CategoryCam Follower
Weight and Dimensions
Inner (d) MM
10
Outer (D) MM
26
Width (B) MM
12
Inner (d) Inch
0.3937
Outer (D) Inch
1.0236
Width (B) Inch
0.4724
Weight (kg)
0.058
Product Properties
Seal
2L - LS-seal at Both Sides
Excenterring
Other Mounting Method
Running Surface
Standard
Suffix description
PPANATR Or NATV Design Support Roller With A Polyamide 66 Axial Sliding And Sealing Ring On Both Sides. Improved Crowned Profile Of The Outer Ring Running Surface, KR Design Cam Follower Have The Same Features As NATR Or NATV, Sizes 16 And 19 Have One Slot In The Head Of The Stud As Standard. Sizes ≥ 22 Have A Recessed Hexagon On Both Ends
Product description
The KR26PPA SKF is a cam follower with needle rollers. These rolling elements combine high load capacity with a compact design. Cam followers are designed for use with various types of tracks. Thanks to a thick-walled outer ring, they can withstand high radial loads. Instead of an inner ring, they feature a solid, threaded stud, enabling easy mounting. Axial loads due to alignment errors or misalignment can be absorbed in both directions. They are not mounted in a housing bore, but a flat (counter) track provides support.
The KR26PPA SKF is equipped with a cage that prevents the rolling elements from coming into contact with each other. This design allows for a controlled movement of the rolling elements. There is lower friction compared to full complement cam followers, allowing for higher rotational speeds and less heat generation. Common applications of cam followers include conveyor systems, linear guidance systems, and cam mechanisms.
