Also known as
KN50100
LBCD50A
LMES50
R0670-050-00
SPM50
TK50
EAN4047643206709
CategoryLinear Ball Bearing
Weight and Dimensions
Inner (d) MM
50
Outer (D) MM
75
Width (B) MM
100
Inner (d) Inch
1.9685
Outer (D) Inch
2.9528
Width (B) Inch
3.937
Weight (kg)
0.44
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Length (L) mm
100
Load capacity dyn. (C min)
9300
Load capacity stat. (C 0 min)
6500
Load capacity stat. (C 0 max)
8300
ECLASS number
23-30-03-01
ECLASS2 number
23-30-03-01
Medias description
Linear ball bearings KN..-B, Lightweight range, closed design, with relubrication facility, adjustable angle
Suffix description
BGuideways And Carriages May Only Be Combined With Each Other Within The Same Accuracy And Interchangeability Class, So A Can Only Be Combined With A, And B Can Only Be Combined With B
