Loading equivalents
Specifications
Availability36 pcs
BrandINA
Item NumberKN40-B-PP INA
Manufacturer Part Number0244636800000
Also known as
KN4080PP
LBCD40A-2LS
LMES40UU
R0670-240-40
SPM40WW
TK40UU
EAN4012802845198
CategoryLinear Ball Bearing
Weight and Dimensions
Inner (d) MM
40
Outer (D) MM
62
Width (B) MM
80
Inner (d) Inch
1.5748
Outer (D) Inch
2.4409
Width (B) Inch
3.1496
Weight (kg)
0.26
Product Properties
Seal
2L - LS-seal at Both Sides
Data from Schaeffler (medias)
Length (L) mm
80
Load capacity dyn. (C min)
6300
Load capacity stat. (C 0 min)
4350
Load capacity stat. (C 0 max)
5600
ECLASS number
23-30-03-01
ECLASS2 number
23-30-03-01
Medias description
Linear ball bearings KN..-B-PP, Lightweight range, closed design, sealed on all sides, with relubrication facility, adjustable angle
Suffix description
BGuideways And Carriages May Only Be Combined With Each Other Within The Same Accuracy And Interchangeability Class, So A Can Only Be Combined With A, And B Can Only Be Combined With B
