Also known as
KN4080
LBCD40A
LMES40
R0670-040-00
SPM40
TK40
EAN4047643206716
CategoryLinear Ball Bearing
Weight and Dimensions
Inner (d) MM
40
Outer (D) MM
62
Width (B) MM
80
Inner (d) Inch
1.5748
Outer (D) Inch
2.4409
Width (B) Inch
3.1496
Weight (kg)
0.26
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Length (L) mm
80
Load capacity dyn. (C min)
6300
Load capacity stat. (C 0 min)
4350
Load capacity stat. (C 0 max)
5600
ECLASS number
23-30-03-01
ECLASS2 number
23-30-03-01
Medias description
Linear ball bearings KN..-B, Lightweight range, closed design, with relubrication facility, adjustable angle
Suffix description
BGuideways And Carriages May Only Be Combined With Each Other Within The Same Accuracy And Interchangeability Class, So A Can Only Be Combined With A, And B Can Only Be Combined With B
