Home › Linear Ball Bearing › KGHA25-PP INA

KGHA25-PP INA

Linear ball bearing and housing units (compact range) KGHA..PP, sealed, greased,

48 pcs in stock

This product is available from stock
Shipment until 18:00 CET on business days
Payment by invoice possible
Track your order with track & trace
Official Schaeffler distributor

Loading equivalents

Specifications

Availability 48 pcs
Brand INA
Item Number KGHA25-PP INA
Manufacturer Part Number 0006684600000
Also known as KH2540/P/PP + GH25
EAN 4012802468656
Category Linear Ball Bearing

Weight and Dimensions

Inner (d) MM 25
Outer (D) MM 55
Width (B) MM 49
Inner (d) Inch 0.9843
Outer (D) Inch 2.1654
Width (B) Inch 1.9291
Weight (kg) 0.496

Product Properties

Seal 2L - LS-seal at Both Sides

Data from Schaeffler (medias)

Height (H) mm 57,5
Length (L) mm 49
Width (b) mm 55
ECLASS number 23-30-03-06
ECLASS2 number 23-30-03-06

Suffix description

PP Lip Seal On Both Sides Of The Bearing

Downloads & Links

Link to manufacturer

Product description

The KGHA25-PP INA is a linear ball bearing unit or ball bushing unit that is part of INA's compact range. The ball bushing is firmly anchored in its housing. The robust aluminum construction of the housing, allows the use of the full load capacity of the bearing. Like all other ball bushing units in the compact design series, the KGHA25-PP INA has a closed design for mounting on unsupported shafts.
