Specifications

• Availability 134 pcs
• Brand INA
• Item Number HFL1826-L564 INA
• Manufacturer Part Number 0016002140962
• Also known as HFL1826

• EAN 4047643006354
• Category Needle Roller and Cage Assembly

Weight and Dimensions

• Inner (d) MM 18
• Outer (D) MM 24
• Width (B) MM 26
• Inner (d) Inch 0.7087
• Outer (D) Inch 0.9449
• Width (B) Inch 1.0236
• Weight (kg) 0.025

Product Properties

• Seal No Seal

Data from Schaeffler (medias)

• Under roller diameter (F w) mm 18
• Radial Static Load Rating C0r (N) 10200
• Radial Dynamic Load Rating Cr (N) 8000
• Basic static load rating, radial (C 0r) "10200.0000"
• Limiting speed for rotating shaft (n GW) 7500
• Limiting speed for rotating outer ring (n GA) 7500
• ECLASS number 23-05-21-90
• ECLASS2 number 23-05-21-90
• Medias description Drawn cup roller clutch HFL, with bearing
