Loading equivalents
Specifications
Availability8,932 pcs
BrandINA
Item NumberHFL0615-KF-R-L564 INA
Manufacturer Part Number0012841000962
Also known as
HFL0615KFR
EAN4012802213058
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
6
Outer (D) MM
10
Width (B) MM
15
Inner (d) Inch
0.2362
Outer (D) Inch
0.3937
Width (B) Inch
0.5906
Weight (kg)
0.004
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm
6
Limiting speed for rotating shaft (n GW)
23000
Limiting speed for rotating outer ring (n GA)
13000
ECLASS number
23-05-21-90
ECLASS2 number
23-05-21-90
Medias description
Drawn cup roller clutches HFL..-KF-R, with plain or rolling bearing arrangement, plastic springs, knurled outer ring
Suffix description
KFPlastic Springs
RPartially Knurled Outer Ring For Assembly In Plastic Housing
L564Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
