Also known as
BS2-2215-2CS/VT143
BS2-2215-2RS
BS2-2215-2RS/VT143
WS22215-E1-2RSR
WS22215-E1-XL-2RSR
CategorySpherical Roller Bearing
Weight and Dimensions
Inner (d) MM
75
Outer (D) MM
130
Width (B) MM
38
Inner (d) Inch
2.9528
Outer (D) Inch
5.1181
Width (B) Inch
1.4961
Weight (kg)
2.1
Product Properties
Bore
C - Cylindrical Bore
Lubrication Enhancement
W33 - Lubrication Groove and 3 Holes
Seal
2RS - Rubber Seal on Two Sides
Cage Type
S - Steel or Standard Cage
Radial Internal Play
Cn Normal Internal Play
Precision
Standard Precision
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution
Non Vibrating Screen Execution
Suffix description
2CSSheet Steel Reinforced Contact Seal Of Acrylonitrile-Butadiene Rubber (NBR) On Both Sides Of The Bearing. Annular Groove And Three Lubrication Holes In The Outer Ring Covered With A Polymer Band. Lubricated With An Extreme Pressure Bearing Grease According To Temperature Range -20 ~ 110℃, Grease Fill 25% To 35%
Product description
The BS2-2215-2CS SKF is a spherical roller bearing with seals on both sides. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.
