Specifications

• Availability 0 pcs
• Brand INA
• Item Number AXW10 INA
• Manufacturer Part Number 0001615780000
• EAN 4012802127072
• Category Needle Roller Thrust Bearing

Weight and Dimensions

• Inner (d) MM 10
• Outer (D) MM 27
• Width (B) MM 3,2
• Inner (d) Inch 0.3937
• Outer (D) Inch 1.063
• Width (B) Inch 0.126
• Weight (kg) 0.0083

Data from Schaeffler (medias)

• Outside diameter bearing washer (D) mm 27
• Height bearing (B) mm 3,2
• Basic dynamic load rating, axial (C) 9200
• Axial Static Load Rating C0a (N) 25500
• Axial Dynamic Load Rating Ca (N) 9200
• Limiting speed (n G) 16900
• Reference speed (n ϑr) 9300
• ECLASS number 23-05-11-02
• ECLASS2 number 23-05-11-02
• Medias description Axial needle roller bearings, single direction, AXK with axial bearing washer
