Specifications

• Availability 67 pcs
• Brand FAG
• Item Number 7602045-TVP FAG
• Manufacturer Part Number 0191192670000
• EAN 4012801166720
• Category Angular Contact Thrust Ball Bearings, Single Direction

Weight and Dimensions

• Inner (d) MM 45
• Outer (D) MM 85
• Width (B) MM 19
• Inner (d) Inch 1.7717
• Outer (D) Inch 3.3465
• Width (B) Inch 0.748
• Weight (kg) 0.51

Product Properties

• Cage Type P - Plastic Molded Cage
• Precision Standard Precision

Data from Schaeffler (medias)

• Width (b) mm 19
• Axial Static Load Rating C0a (N) 111000
• Axial Dynamic Load Rating Ca (N) 39500
• Limiting speed for grease lubrication (n G Grease) 4700
• Thermally safe operating speed (n ϑ) 2600
• ECLASS number 23-05-10-02
• ECLASS2 number 23-05-10-02
• Medias description Axial angular contact ball bearing 7602..-TVP, single direction, no screw mounting
