Specifications

• Availability 18 pcs expected on Tue 22 Apr
• Brand FAG
• Item Number 6309-Z-C4 FAG
• Manufacturer Part Number 0167235970040
• EAN 4012801279239
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 45
• Outer (D) MM 100
• Width (B) MM 25
• Inner (d) Inch 1.7717
• Outer (D) Inch 3.937
• Width (B) Inch 0.9843
• Weight (kg) 0.84

Product Properties

• Bore C - Cylindrical Bore
• Seal Z - Steel Seal on One Side
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play C4 Internal Play (Higher than C3)
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 25
• Radial Static Load Rating C0r (N) 31500
• Radial Dynamic Load Rating Cr (N) 56000
• Basic static load rating, radial (C 0r) "31500.0000"
• Limiting speed (n G) 9500
• Reference speed (n ϑr) 8200
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearing 63..-Z, single row, cf. DIN 625-1
