Specifications

• Availability 89 pcs
• Brand FAG
• Item Number 62208-A-2RSR FAG
• Manufacturer Part Number 0648003930000
• EAN 4012802615135
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 40
• Outer (D) MM 80
• Width (B) MM 23
• Inner (d) Inch 1.5748
• Outer (D) Inch 3.1496
• Width (B) Inch 0.9055
• Weight (kg) 0.47

Product Properties

• Bore C - Cylindrical Bore
• Seal 2RS - Rubber Seal on Two Sides
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 23
• Radial Static Load Rating C0r (N) 17900
• Radial Dynamic Load Rating Cr (N) 29110
• Basic static load rating, radial (C 0r) "17900.0000"
• Limiting speed (n G) 5000
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
