Specifications

• Availability 167 pcs
• Brand FAG
• Item Number 6217 FAG
• Manufacturer Part Number 0167214380000
• EAN 4012801077422
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 85
• Outer (D) MM 150
• Width (B) MM 28
• Inner (d) Inch 3.3465
• Outer (D) Inch 5.9055
• Width (B) Inch 1.1024
• Weight (kg) 1.79

Product Properties

• Bore C - Cylindrical Bore
• Seal No Seal
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 28
• Radial Static Load Rating C0r (N) 64000
• Radial Dynamic Load Rating Cr (N) 89000
• Basic static load rating, radial (C 0r) "64000.0000"
• Limiting speed (n G) 6700
• Reference speed (n ϑr) 5300
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearing 62, single row, cf. DIN 625-1
