Specifications

• Availability 1,275 pcs
• Brand FAG
• Item Number 6205-C-C3 FAG
• Manufacturer Part Number 0621661400030
• Also known as 6205-C3

• EAN 4012802384185
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 25
• Outer (D) MM 52
• Width (B) MM 15
• Inner (d) Inch 0.9843
• Outer (D) Inch 2.0472
• Width (B) Inch 0.5906
• Weight (kg) 0.125

Product Properties

• Bore C - Cylindrical Bore
• Seal No Seal
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play C3 Internal Play (Higher than Cn)
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 15
• Radial Static Load Rating C0r (N) 7800
• Radial Dynamic Load Rating Cr (N) 15900
• Basic static load rating, radial (C 0r) "7800.0000"
• Limiting speed (n G) 21600
• Reference speed (n ϑr) 16000
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearing 62..-C, single row, cf. DIN 625-1
