Specifications

• Availability 1,334 pcs
• Brand FAG
• Item Number 6204-C-2Z-C3 FAG
• Manufacturer Part Number 0593721090030
• Also known as 6204-2Z/C3
  6204-2Z-C3

• EAN 4012802383676
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 20
• Outer (D) MM 47
• Width (B) MM 14
• Inner (d) Inch 0.7874
• Outer (D) Inch 1.8504
• Width (B) Inch 0.5512
• Weight (kg) 0.107

Product Properties

• Bore C - Cylindrical Bore
• Seal ZZ/2Z - Steel Seal on Two Sides
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play C3 Internal Play (Higher than Cn)
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 14
• Radial Static Load Rating C0r (N) 6600
• Radial Dynamic Load Rating Cr (N) 13900
• Basic static load rating, radial (C 0r) "6600.0000"
• Limiting speed (n G) 20600
• Reference speed (n ϑr) 18100
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearing 62..-C-2Z, single row, cf. DIN 625-1
