Specifications

• Availability 29 pcs
• Brand FAG
• Item Number 61814-2RSR-Y FAG
• Manufacturer Part Number 0797470510000
• Also known as 6814-2RS-Y

• EAN 4047643334945
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 70
• Outer (D) MM 90
• Width (B) MM 10
• Inner (d) Inch 2.7559
• Outer (D) Inch 3.5433
• Width (B) Inch 0.3937
• Weight (kg) 0.134

Product Properties

• Bore C - Cylindrical Bore
• Seal 2RS - Rubber Seal on Two Sides
• Cage Type Y - Pressed Brass Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 10
• Radial Static Load Rating C0r (N) 12400
• Radial Dynamic Load Rating Cr (N) 13200
• Basic static load rating, radial (C 0r) "12400.0000"
• Limiting speed (n G) 3500
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearings 618..-2RSR, main dimensions to DIN 625-1, lip seals on both sides
