Specifications

• Availability 10 pcs expected on Tue 14 Jan
• Brand FAG
• Item Number 6014-RSR FAG
• Manufacturer Part Number 0190939000000
• EAN 4012801274180
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 70
• Outer (D) MM 110
• Width (B) MM 20
• Inner (d) Inch 2.7559
• Outer (D) Inch 4.3307
• Width (B) Inch 0.7874
• Weight (kg) 0.602

Product Properties

• Bore C - Cylindrical Bore
• Seal RS - Rubber Seal on One Side
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 20
• Radial Static Load Rating C0r (N) 31000
• Radial Dynamic Load Rating Cr (N) 40500
• Basic static load rating, radial (C 0r) "31000.0000"
• Limiting speed (n G) 3250
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearing 60..-RSR, single row, cf. DIN 625-1
