Specifications

• Availability 481 pcs
• Brand FAG
• Item Number 6003-C3 FAG
• Manufacturer Part Number 0167170150030
• EAN 4012801053365
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 17
• Outer (D) MM 35
• Width (B) MM 10
• Inner (d) Inch 0.6693
• Outer (D) Inch 1.378
• Width (B) Inch 0.3937
• Weight (kg) 0.039

Product Properties

• Bore C - Cylindrical Bore
• Seal No Seal
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play C3 Internal Play (Higher than Cn)
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 10
• Radial Static Load Rating C0r (N) 3250
• Radial Dynamic Load Rating Cr (N) 6400
• Basic static load rating, radial (C 0r) "3250.0000"
• Limiting speed (n G) 31000
• Reference speed (n ϑr) 20300
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearing 60, single row, cf. DIN 625-1
