Also known as
6002-2Z/C3
6002-2Z-C3
6002ZZ C3
6002ZZ J30
EAN7316570529883
CategoryDeep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM
15
Outer (D) MM
32
Width (B) MM
9
Inner (d) Inch
0.5906
Outer (D) Inch
1.2598
Width (B) Inch
0.3543
Weight (kg)
0.031
Product Properties
Bore
C - Cylindrical Bore
Seal
ZZ/2Z - Steel Seal on Two Sides
Cage Type
S - Steel or Standard Cage
External Modification
No External Modification
Radial Internal Play
C3 Internal Play (Higher than Cn)
Precision
Standard Precision
Lubrication
High Temperature Grease
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Special Treatment
No Special Treatment
Suffix description
2ZShield Of Pressed Sheet Steel On Both Sides Of The Bearing
C3Internal Clearance Larger Than Normal
WTGrease Fill For Low As Well As High Temperature e.g. Range -40 ~ 160°C. WT Or A Two-Figure Number Following WT Identifies The Actual Grease. An Additional Letter Or Letter/ Figure Combination As Mentioned Under “HT” Identifies Filling Degrees Other Than Standard
