Specifications

• Availability 0 pcs
• Brand INA
• Item Number 3812-2Z INA
• Manufacturer Part Number 0009721770000
• EAN 4012802882155
• Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

• Inner (d) MM 60
• Outer (D) MM 78
• Width (B) MM 14
• Inner (d) Inch 2.3622
• Outer (D) Inch 3.0709
• Width (B) Inch 0.5512
• Weight (kg) 0.15

Product Properties

• Bore C - Cylindrical Bore
• Seal ZZ/2Z - Steel Seal on Two Sides
• Cage Type P - Plastic Molded Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Split Inner ring / Outer ring Standard

Data from Schaeffler (medias)

• Width (b) mm 14
• Radial Static Load Rating C0r (N) 17100
• Radial Dynamic Load Rating Cr (N) 14200
• Basic static load rating, radial (C 0r) "17100.0000"
• Limiting speed (n G) 6600
• Reference speed (n ϑr) 4700
• ECLASS number 23-05-08-03
• ECLASS2 number 23-05-08-03
• Medias description Angular contact ball bearing 38..-B-2RZ-TVH, double row, 1 inner ring
