Specifications

• Availability 63 pcs
• Brand INA
• Item Number 3808-2Z INA
• Manufacturer Part Number 0009720880000
• EAN 4012802460346
• Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

• Inner (d) MM 40
• Outer (D) MM 52
• Width (B) MM 10
• Inner (d) Inch 1.5748
• Outer (D) Inch 2.0472
• Width (B) Inch 0.3937
• Weight (kg) 0.04

Product Properties

• Bore C - Cylindrical Bore
• Seal ZZ/2Z - Steel Seal on Two Sides
• Cage Type P - Plastic Molded Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Split Inner ring / Outer ring Standard

Data from Schaeffler (medias)

• Width (b) mm 10
• Radial Static Load Rating C0r (N) 7600
• Radial Dynamic Load Rating Cr (N) 6900
• Basic static load rating, radial (C 0r) "7600.0000"
• Limiting speed (n G) 10300
• Reference speed (n ϑr) 6300
• ECLASS number 23-05-08-03
• ECLASS2 number 23-05-08-03
• Medias description Angular contact ball bearing 38..-B-2RZ-TVH, double row, 1 inner ring
