Specifications
Availability
1 pc
Brand
FAG
Item Number
239/750-MB-C3 FAG
Manufacturer Part Number
0190411440030
EAN
4012801975209
Category
Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM
750
Outer (D) MM
1000
Width (B) MM
185
Inner (d) Inch
29.5276
Outer (D) Inch
39.3701
Width (B) Inch
7.2835
Weight (kg)
420
Product Properties
Bore
C - Cylindrical Bore
Lubrication Enhancement
W33 - Lubrication Groove and 3 Holes
Seal
No Seal
Cage Type
M - Brass Cage
Radial Internal Play
C3 Internal Play (Higher than Cn)
Precision
Standard Precision
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution
Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm
185
Radial Static Load Rating C0r (N)
13000000
Radial Dynamic Load Rating Cr (N)
5200000
Basic static load rating, radial (C 0r)
"13000000.0000"
Limiting speed (n G)
640
Reference speed (n ϑr)
325
ECLASS number
23-05-09-11
ECLASS2 number
23-05-09-11
Medias description
Spherical roller bearing 239..-MB, symmetric 3 ribs
Suffix description
MB
Solid Brass Cage, Guidance On Inner Ring
C3
Internal Clearance Larger Than Normal
Downloads & Links
Product description
The 239/750-MB-C3 FAG is a spherical roller bearing. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.
