3 pcs in stock
5 pcs expected on Tue 3 Dec
45 pcs expected on Fri 6 Dec
This product is available from stock
Shipment until 18:00 CET on business days
Payment by invoice possible
Track your order with track & trace
Loading equivalents
Specifications
Availability53 pcs
BrandSKF
Item Number22211EK SKF
EAN7316576652165
CategorySpherical Roller Bearing
Weight and Dimensions
Inner (d) MM
55
Outer (D) MM
100
Width (B) MM
25
Inner (d) Inch
2.1654
Outer (D) Inch
3.937
Width (B) Inch
0.9843
Weight (kg)
0.8
Product Properties
Bore
K - 1:12 Tapered Bore (Standard for Most Types)
Lubrication Enhancement
W33 - Lubrication Groove and 3 Holes
Seal
No Seal
Cage Type
S - Steel or Standard Cage
Radial Internal Play
Cn Normal Internal Play
Precision
Standard Precision
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution
Non Vibrating Screen Execution
Suffix description
Ed ≤65mm, Two Window-Type Steel Cages, Flangeless Inner Ring And Guide Centered On The Inner Ring. When d >65 mm Same As <65mm But Guide Ring Centered On The Cages
KTapered Bore, Taper 1:12
Product description
The 22211EK SKF is a spherical roller bearing with an open design. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.
