Specifications
Availability5 pcs
BrandSKF
Item Number1216K/C3 SKF
EAN7316576608582
CategorySelf Aligning Ball Bearing Double Row
Weight and Dimensions
Inner (d) MM
80
Outer (D) MM
140
Width (B) MM
26
Inner (d) Inch
3.1496
Outer (D) Inch
5.5118
Width (B) Inch
1.0236
Weight (kg)
1.64
Product Properties
Bore
K - 1:12 Tapered Bore (Standard for Most Types)
Seal
No Seal
Cage Type
S - Steel or Standard Cage
Radial Internal Play
C3 Internal Play (Higher than Cn)
Precision
Standard Precision
Lubrication
Standard Lubrication
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Suffix description
KTapered Bore, Taper 1:12
C3Radial Internal Clearance Greater Than Normal
Product description
The 1216K/C3 SKF belongs to the group of double-row self-aligning deep-groove ball bearings. This bearing type without a seal is a double-row bearing. Both rows are housed in a spherical raceway in the outer ring. This construction allows the bearing to be self-aligning. This means that any misalignment of the shaft relative to the bearing housing does not adversely affect performance.
These features make the 1216K/C3 SKF highly suitable for applications where substantial misalignment or shaft deflections may occur. Also, self-aligning bearings have the lowest friction of all rolling-element bearings. Even at higher speeds, there is only limited frictional heat. These bearings are capable of handling high radial loads. To a lesser extent, they can be axially loaded in both directions.
